How to Deploy Zabbix Server on Google Cloud?

13 minutes read

Deploying Zabbix server on Google Cloud involves several steps:

  1. Provision a Google Cloud virtual machine: Go to the Google Cloud console and create a new virtual machine instance. Choose an appropriate machine type, network, and disk size for the Zabbix server.
  2. Set up the virtual machine operating system: During the virtual machine creation, select a suitable operating system, such as Ubuntu or CentOS. Ensure that the necessary firewall rules are configured to allow incoming connections to the Zabbix server.
  3. Connect to the virtual machine: Use SSH or any other supported method to connect to the virtual machine using a terminal or remote desktop.
  4. Install required dependencies: Update the system packages and install the necessary dependencies for Zabbix server to run smoothly. This may include packages like Apache or Nginx, PHP, MySQL (or PostgreSQL), and other required libraries.
  5. Configure the web server: If you are using Apache or Nginx as the web server, modify the server configuration to set up virtual hosts or server blocks for Zabbix. Ensure that the web server is correctly configured to serve PHP files.
  6. Install and configure Zabbix server: Download the Zabbix server software and follow the installation instructions provided by Zabbix. This usually involves importing a MySQL or PostgreSQL database schema, configuring the server settings, and starting the Zabbix server process.
  7. Set up a database for Zabbix server: Create a new database and user for Zabbix server to store its data. Grant necessary privileges to the user to access the database.
  8. Configure Zabbix frontend: Access the Zabbix web interface using a web browser and configure the frontend settings. This involves providing the database details, setting up an initial user, and configuring basic options like server monitoring intervals.
  9. Test and verify: Once the installation and configuration are complete, verify that the Zabbix server is working properly. Test monitoring of a few hosts or services to ensure that data is being collected and displayed correctly.
  10. Enable external access (if required): If you want to access the Zabbix server remotely over the internet, configure any necessary firewall rules, domain or DNS settings, and SSL certificates for secure access.

Remember to regularly update and maintain your Zabbix server by applying security patches and updates provided by Zabbix and the operating system vendor.

Best Cloud Hosting Services of 2024


Rating is 5 out of 5



Rating is 5 out of 5



Rating is 4.9 out of 5



Rating is 4.9 out of 5


What is Zabbix web monitoring and how to set it up for Google Cloud applications?

Zabbix web monitoring is a feature provided by the Zabbix monitoring tool that allows you to monitor the availability and performance of websites and web applications. It periodically sends HTTP requests to the specified URLs and checks the responses according to defined criteria, helping you to identify issues and ensure the smooth functioning of your web applications.

To set up Zabbix web monitoring for Google Cloud applications, you can follow these steps:

  1. Install and configure Zabbix server: Set up a Zabbix server on a machine that meets the necessary requirements. Install the Zabbix server software and configure it with the appropriate settings.
  2. Add a host in Zabbix: Create a new Zabbix host for monitoring your Google Cloud application. Provide the necessary details such as the host name, DNS name or IP address, and choose an appropriate group.
  3. Configure web scenario: Create a web scenario in Zabbix to monitor the availability and performance of your Google Cloud application. Specify the URL, required authentication, and other parameters like expected response codes and response time thresholds.
  4. Set up triggers and actions: Define triggers based on the web scenario results. Triggers can help you detect specific conditions or errors in the monitored application. Configure actions to be taken when any trigger is activated, such as sending notifications or running custom scripts.
  5. Set up the Zabbix agent: Install the Zabbix agent on the Google Cloud instances running your application (if necessary). The agent collects additional metrics and can help in correlating web scenario results with system-level performance metrics.
  6. Test and monitor: Test the web scenario by running it manually. Monitor the gathered data through the Zabbix front-end to ensure that the web monitoring is working as expected.

By following these steps, you should be able to set up Zabbix web monitoring for your Google Cloud applications and have insight into the availability and performance of your web applications.

What is Zabbix API and how to interact with it on Google Cloud?

Zabbix API is a web-based interface that allows users to interact with the Zabbix monitoring software programmatically. It enables users to perform various tasks such as retrieving monitoring data, managing hosts, triggers, and notifications, creating or updating configuration items, and more.

To interact with Zabbix API on Google Cloud, you'll need to follow these steps:

  1. Set up a virtual machine (VM) on Google Cloud: Launch a VM instance on the Google Cloud platform, either using Compute Engine or Kubernetes Engine. Ensure that the VM has appropriate network access and firewall rules to communicate with your Zabbix server.
  2. Install Zabbix server: Install the Zabbix server on the VM. You can do this by following the official Zabbix installation guide for your operating system.
  3. Configure Zabbix server: After installing the Zabbix server, configure it according to your requirements. This includes setting up monitoring targets, defining triggers, notifications, and other necessary configurations.
  4. Enable Zabbix API: Enable the Zabbix API by modifying the Zabbix server configuration file. Typically, this file is located at /etc/zabbix/zabbix_server.conf. Ensure that the APIEnabled parameter is set to 1.
  5. Restart Zabbix server: After making changes to the Zabbix server configuration, restart the Zabbix server to apply the changes.
  6. Obtain Zabbix API URL and credentials: Retrieve the URL of the Zabbix API endpoint (e.g., http:///zabbix/api_jsonrpc.php). Additionally, obtain the credentials required to authenticate with the Zabbix API. This can be done by creating an API user within the Zabbix server.
  7. Interact with Zabbix API: Use your preferred programming language or REST client to interact with the Zabbix API. Send HTTP requests to the Zabbix API endpoint, providing the necessary parameters and credentials, to invoke specific API methods and retrieve or manipulate monitoring data.

By following these steps, you'll be able to interact with the Zabbix API on Google Cloud and leverage its capabilities to monitor your infrastructure efficiently.

How to set up Zabbix proxies for distributed monitoring on Google Cloud?

Setting up Zabbix proxies for distributed monitoring on Google Cloud involves the following steps:

  1. Create Google Cloud instances: Create a new Google Cloud project if you haven't already. Create instances that will act as Zabbix proxies. Depending on your requirements and scale, you may need multiple instances distributed across different regions. Configure the instances with appropriate machine type, disk size, and other settings.
  2. Install Zabbix Proxy: SSH into each instance and install the Zabbix Proxy on them. Follow the Zabbix documentation or use package managers like apt or yum to install the Zabbix Proxy package.
  3. Configure Zabbix Proxy: Edit the Zabbix Proxy configuration file (typically /etc/zabbix/zabbix_proxy.conf) on each instance. Update the required settings like Server, Hostname, ListenIP, DBName, DBUser, DBPassword, etc., according to your Zabbix server and database setup. Ensure that the proxy can connect to the Zabbix server.
  4. Enable necessary ports: On each instance, make sure that the required ports for Zabbix Proxy are open in the firewall settings. By default, Zabbix Proxy uses ports 10051 (for Zabbix server) and 10050 (for monitored hosts). Refer to the Google Cloud documentation for instructions on opening ports.
  5. Start Zabbix Proxy: Start the Zabbix Proxy service on each instance using the appropriate command for your OS. For example: systemctl start zabbix-proxy # For systemd-based systems service zabbix-proxy start # For SysV init systems
  6. Add Zabbix Proxy to Zabbix Server: Log in to your Zabbix Server web interface. Go to Configuration > Hosts and select the Zabbix Proxy tab. Click on "Create Proxy" and fill in the required fields like Proxy Name, Proxy mode, Proxy IP/DNS, etc. Ensure that the Proxy IP is the external IP of your Google Cloud instance.
  7. Associate monitored hosts with Zabbix Proxy: Edit the host settings for each monitored host in Zabbix. Under the "Proxy" tab, select your Zabbix Proxy for that host. Save the configuration.
  8. Test the configuration: Verify that the Zabbix Proxy is connected to the Zabbix Server by checking the Zabbix Proxy status in the web interface under Monitoring > Proxies. Monitor the log file of Zabbix Proxy on each instance (/var/log/zabbix/zabbix_proxy.log) for any issues or error messages.

By following these steps, you should be able to set up Zabbix proxies on Google Cloud for distributed monitoring.

How to create user roles and permissions in Zabbix for Google Cloud monitoring?

To create user roles and permissions in Zabbix for Google Cloud monitoring, you can follow these steps:

  1. Login to your Zabbix web interface and navigate to the "Administration" tab.
  2. Under the "Administration" menu, click on "Users" to access the user management page.
  3. Click on the "Create user" button to create a new user.
  4. Fill in the required user details, such as username, password, and name.
  5. In the "Groups" section, select the appropriate user group or create a new group for the user.
  6. In the "Roles" section, click on the "Select" button to choose the roles you want to assign to the user.
  7. In the "Permissions" section, you can define specific permissions for the user.
  8. Click on the "Add" button to add a new permission.
  9. In the "Resource type" dropdown menu, select "Google Cloud".
  10. Specify the resource that the user should have access to by selecting the appropriate project, folder, or organization.
  11. Choose the desired level of access for the user, such as read-only or read-write.
  12. Click on the "Add" button to create the permission.
  13. Repeat steps 8 to 12 to add more permissions if needed.
  14. Once you have assigned the appropriate roles and permissions, click on the "Add" button to create the user.
  15. The user will now have the specified roles and permissions for Google Cloud monitoring in Zabbix.

Note: Make sure you have the necessary Google Cloud credentials and the Zabbix Google Cloud plugin configured properly to enable monitoring of your Google Cloud resources.

What are Zabbix agents and how to install them on Google Cloud instances?

Zabbix agents are software programs that run on monitored devices and collect data to send to the Zabbix server for analysis and visualization. They allow monitoring of various metrics like CPU usage, memory utilization, network traffic, disk utilization, and more.

To install Zabbix agents on Google Cloud instances, you can follow these steps:

  1. Set up a Google Cloud instance: Create a new virtual machine instance on Google Cloud or use an existing one, ensuring that it has access to the internet.
  2. SSH into the instance: Connect to the Google Cloud instance using SSH.
  3. Download the Zabbix agent package: Use the wget command to download the Zabbix agent package. For example: wget
  4. Install the Zabbix agent package: Install the downloaded package using the dpkg command. For example: sudo dpkg -i zabbix-release_5.4-1+bionic_all.deb
  5. Update the package cache: Run the following command to update the package cache: sudo apt update
  6. Install the Zabbix agent: Now you can install the Zabbix agent using the apt command: sudo apt install zabbix-agent
  7. Configure the Zabbix agent: Open the Zabbix agent configuration file using a text editor. For example: sudo nano /etc/zabbix/zabbix_agentd.conf Within the configuration file, you can set the Zabbix server IP address, specify which metrics to monitor, provide a unique hostname for the agent, etc. Modify these settings as per your requirements.
  8. Start the Zabbix agent: Start the Zabbix agent service using the following command: sudo systemctl start zabbix-agent
  9. Enable the Zabbix agent: Ensure that the Zabbix agent starts automatically on system boot by enabling it with this command: sudo systemctl enable zabbix-agent

That's it! The Zabbix agent should now be installed and running on your Google Cloud instance, ready to send data to your Zabbix server for monitoring and analysis.

What is Zabbix preprocessing and how to utilize it for Google Cloud monitoring?

Zabbix preprocessing is a feature that allows you to configure and manipulate collected data before storing it in the Zabbix database. It enables you to transform data by applying various operations such as data type conversion, regular expression matching, string replacement, mathematical calculations, and more.

To utilize Zabbix preprocessing for Google Cloud monitoring, you can follow these steps:

  1. Install and configure Zabbix server and agent on your monitoring server and Google Cloud instances respectively.
  2. In the Zabbix web interface, navigate to the "Administration" section and select "Preprocessing" under the "Extensions" category.
  3. Click on "Create preprocessing" to define a new preprocessing rule. Provide a name and select the host or group to apply the preprocessing to.
  4. Specify the preprocessing settings, including the type of operation you want to perform (e.g., regex matching, string replacement, data type conversion), the input field that needs processing, and the output field where the result will be stored.
  5. Configure the parameters for the selected operation, such as regular expressions or replacement strings.
  6. Save the preprocessing rule, and it will be applied to the specified host or group during data collection.

By using Zabbix preprocessing, you can format and manipulate the collected data from Google Cloud before storing it in the Zabbix database. This allows you to extract specific information, normalize values, or convert data types to better suit your monitoring needs.
