How to Make A Responsive Chart With Chart.js?

10 minutes read

To make a responsive chart with Chart.js, you first need to include the Chart.js library in your project. Next, create a canvas element in your HTML file where the chart will be displayed. Then, initialize Chart.js by creating a new Chart object and passing in the canvas element as well as the chart configuration options.


To ensure that the chart is responsive and adjusts to different screen sizes, set the responsive and maintainAspectRatio options to true in the chart configuration. This will allow the chart to resize based on the dimensions of its parent container.


You can also set specific chart options to customize its appearance and behavior, such as setting the type of chart (e.g., line, bar, pie), defining the data to be displayed, and configuring colors, labels, and tooltips.


Finally, you can update the chart data dynamically by updating the chart data object and calling the update() method on the Chart object. This will redraw the chart with the new data.


By following these steps and customizing the chart options as needed, you can create a responsive and interactive chart using Chart.js.

Best Javascript Books to Read in 2024

1
JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

Rating is 5 out of 5

JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

2
JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

Rating is 4.9 out of 5

JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

3
JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

Rating is 4.8 out of 5

JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

4
Web Design with HTML, CSS, JavaScript and jQuery Set

Rating is 4.7 out of 5

Web Design with HTML, CSS, JavaScript and jQuery Set

5
JavaScript Crash Course: A Hands-On, Project-Based Introduction to Programming

Rating is 4.6 out of 5

JavaScript Crash Course: A Hands-On, Project-Based Introduction to Programming

6
Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

Rating is 4.5 out of 5

Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

7
Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

Rating is 4.4 out of 5

Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

8
JavaScript and jQuery: Interactive Front-End Web Development

Rating is 4.3 out of 5

JavaScript and jQuery: Interactive Front-End Web Development


How to hide specific elements in a Chart.js chart?

To hide specific elements in a Chart.js chart, you can use the options parameter when creating the chart and set the display property to false for the specific element you want to hide. Here's an example:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
var ctx = document.getElementById('myChart').getContext('2d');

var myChart = new Chart(ctx, {
    type: 'bar',
    data: {
        labels: ['Red', 'Blue', 'Yellow', 'Green', 'Purple', 'Orange'],
        datasets: [{
            label: 'My Dataset',
            data: [12, 19, 3, 5, 2, 3],
            backgroundColor: [
                'rgba(255, 99, 132, 0.2)',
                'rgba(54, 162, 235, 0.2)',
                'rgba(255, 206, 86, 0.2)',
                'rgba(75, 192, 192, 0.2)',
                'rgba(153, 102, 255, 0.2)',
                'rgba(255, 159, 64, 0.2)'
            ],
            borderColor: [
                'rgba(255, 99, 132, 1)',
                'rgba(54, 162, 235, 1)',
                'rgba(255, 206, 86, 1)',
                'rgba(75, 192, 192, 1)',
                'rgba(153, 102, 255, 1)',
                'rgba(255, 159, 64, 1)'
            ],
            borderWidth: 1
        }]
    },
    options: {
        scales: {
            yAxes: [{
                ticks: {
                    beginAtZero: true
                }
            }]
        },
        legend: {
            display: false // hides the legend
        },
        tooltips: {
            enabled: false // hides the tooltips
        }
    }
});


In this example, the legend and tooltips have been hidden using the options parameter. You can also hide other elements such as the gridlines, tick marks, etc. by setting their display property to false in the options object.


What is the default animation duration in Chart.js?

The default animation duration in Chart.js is 1000 milliseconds (1 second).


How to change the line style in a line chart with Chart.js?

To change the line style in a line chart with Chart.js, you can use the borderColor and borderDash properties of the dataset in the chart configuration. Here's an example of how you can change the line style to a dashed line:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
var ctx = document.getElementById('myChart').getContext('2d');
var myChart = new Chart(ctx, {
    type: 'line',
    data: {
        labels: ['January', 'February', 'March', 'April', 'May', 'June', 'July'],
        datasets: [{
            label: 'My Dataset',
            data: [10, 20, 30, 40, 50, 60, 70],
            borderColor: 'blue', // change the color of the line
            borderDash: [5, 5] // make the line dashed with a 5px dash and 5px gap
        }]
    },
    options: {
        // add any additional options here
    }
});


In this example, the borderColor property is used to change the color of the line to blue, and the borderDash property is used to specify a dashed line with a 5px dash and 5px gap. You can customize the dash and gap lengths as needed to achieve the desired line style.


How to create a horizontal bar chart using Chart.js?

To create a horizontal bar chart using Chart.js, follow these steps:

  1. Include the Chart.js library in your HTML file:
1
<script src="https://cdn.jsdelivr.net/npm/chart.js"></script>


  1. Create a canvas element in your HTML file where you want to display the chart:
1
<canvas id="myChart" width="400" height="200"></canvas>


  1. Create a JavaScript function to render the horizontal bar chart:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
var ctx = document.getElementById('myChart').getContext('2d');
var myChart = new Chart(ctx, {
    type: 'horizontalBar',
    data: {
        labels: ['January', 'February', 'March', 'April', 'May'],
        datasets: [{
            data: [10, 20, 30, 40, 50],
            backgroundColor: 'rgba(54, 162, 235, 0.2)',
            borderColor: 'rgba(54, 162, 235, 1)',
            borderWidth: 1
        }]
    },
    options: {
        scales: {
            xAxes: [{
                ticks: {
                    beginAtZero: true
                }
            }]
        }
    }
});


  1. Customize the data and options according to your requirements. In this example, we have set the labels as months and the data values as random numbers for each month.
  2. Call the JavaScript function to render the chart when the page is loaded or as needed:
1
2
3
window.onload = function() {
    renderChart();
}


  1. Your horizontal bar chart should now be displayed on the canvas element specified in your HTML. You can further customize the chart by adding more datasets, styling the colors, adjusting the scales, and other configurations based on your needs.


How to create a gauge chart with Chart.js?

To create a gauge chart with Chart.js, you can follow these steps:

  1. First, include Chart.js library in your HTML file. You can either download the library and include it locally, or use a CDN link to include it from a remote server. Here is an example of including Chart.js with a CDN link:
1
<script src="https://cdn.jsdelivr.net/npm/chart.js"></script>


  1. Next, create a canvas element in your HTML file where the gauge chart will be rendered:
1
<canvas id="gaugeChart"></canvas>


  1. Create a JavaScript file where you will write the code to create the gauge chart. In this file, you will need to write the JavaScript code to configure and render the gauge chart using Chart.js. Here is an example of how you can create a basic gauge chart:
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
// Get the canvas element
var ctx = document.getElementById('gaugeChart').getContext('2d');

// Create the gauge chart
var gaugeChart = new Chart(ctx, {
    type: 'gauge',
    data: {
        datasets: [{
            data: [70],
            backgroundColor: ['rgba(255,99,132,0.8)'],
        }],
    },
    options: {
        circumference: Math.PI,
        rotation: Math.PI,
        title: {
            display: true,
            text: 'Gauge Chart'
        },
	      tooltips: {
            enabled: false
        }
    }
});


  1. Customize the gauge chart as needed by modifying the data and options properties of the gaugeChart object.
  2. Your gauge chart should now render on the canvas element specified in your HTML file.


Keep in mind that the gauge chart type is not natively supported by Chart.js, so you may need to use a plugin or extension to create a gauge chart. One popular plugin for creating gauge charts with Chart.js is chartjs-gauge. You can find more information on how to use this plugin in the Chart.js documentation.
