How to Add Additional Information to Chart.js Tooltip?

9 minutes read

To add additional information to a Chart.js tooltip, you can customize the tooltip callback function in your Chart.js configuration. Within the tooltip callback function, you can access the tooltip label and dataset index, allowing you to retrieve additional information from your dataset or other sources. You can then customize the tooltip content by concatenating the additional information with the default tooltip content before returning the final tooltip text to be displayed. This way, you can enhance the tooltip display with meaningful context or details that provide more insights to the users of your chart.

Best Javascript Books to Read in 2024

1
JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

Rating is 5 out of 5

JavaScript: The Comprehensive Guide to Learning Professional JavaScript Programming (The Rheinwerk Computing)

2
JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

Rating is 4.9 out of 5

JavaScript: The Definitive Guide: Master the World's Most-Used Programming Language

3
JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

Rating is 4.8 out of 5

JavaScript from Beginner to Professional: Learn JavaScript quickly by building fun, interactive, and dynamic web apps, games, and pages

4
Web Design with HTML, CSS, JavaScript and jQuery Set

Rating is 4.7 out of 5

Web Design with HTML, CSS, JavaScript and jQuery Set

5
JavaScript Crash Course: A Hands-On, Project-Based Introduction to Programming

Rating is 4.6 out of 5

JavaScript Crash Course: A Hands-On, Project-Based Introduction to Programming

6
Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

Rating is 4.5 out of 5

Learning JavaScript Design Patterns: A JavaScript and React Developer's Guide

7
Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

Rating is 4.4 out of 5

Eloquent JavaScript, 3rd Edition: A Modern Introduction to Programming

8
JavaScript and jQuery: Interactive Front-End Web Development

Rating is 4.3 out of 5

JavaScript and jQuery: Interactive Front-End Web Development


How to adjust tooltip size in chart.js?

To adjust the tooltip size in Chart.js, you can use the tooltip configuration options provided by Chart.js.


Here's an example code snippet showing how you can adjust the tooltip size in a Chart.js chart:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
var chart = new Chart(ctx, {
    type: 'bar',
    data: data,
    options: {
        tooltips: {
            titleFontSize: 16,
            bodyFontSize: 14,
            footerFontSize: 12
        }
    }
});


In the above example, you can adjust the size of the tooltip title, body, and footer text by setting the titleFontSize, bodyFontSize, and footerFontSize options within the tooltips configuration object.


You can adjust these font sizes to increase or decrease the size of the tooltip text as needed for your chart.


How to display additional data in chart.js tooltip?

To display additional data in a Chart.JS tooltip, you can customize the tooltip using the tooltips configuration option. Here's an example of how you can add additional data to the tooltip:

 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
var chartData = {
  labels: ['January', 'February', 'March', 'April', 'May', 'June'],
  datasets: [{
    label: 'Sales',
    data: [10, 20, 30, 40, 50, 60]
  }]
};

var ctx = document.getElementById('myChart').getContext('2d');

var myChart = new Chart(ctx, {
  type: 'line',
  data: chartData,
  options: {
    tooltips: {
      callbacks: {
        label: function(tooltipItem, data) {
          var label = data.datasets[tooltipItem.datasetIndex].label || '';

          if (label) {
            label += ': ';
          }
          label += tooltipItem.yLabel + ' units';

          // Additional data
          label += ' - Additional Data: ' + tooltipItem.xLabel;

          return label;
        }
      }
    }
  }
});


In this example, we have added the Additional Data: <xLabel> to the tooltip by accessing the xLabel property of the tooltipItem. You can customize the tooltip further by adding more data or formatting the data as needed.


How to add tooltips to a doughnut chart in chart.js?

To add tooltips to a doughnut chart in Chart.js, you can follow these steps:

  1. In your HTML file, include the Chart.js library and create a canvas element where the doughnut chart will be rendered. Make sure to give the canvas element an id attribute for easy reference.
1
<canvas id="myDoughnutChart"></canvas>


  1. In your JavaScript file, create a new Chart instance and specify the type of chart as "doughnut". Pass in the data and options for the chart, including the tooltips configuration.
 1
 2
 3
 4
 5
 6
 7
 8
 9
10
11
12
13
14
15
16
17
18
19
20
21
22
var ctx = document.getElementById('myDoughnutChart').getContext('2d');
var myChart = new Chart(ctx, {
  type: 'doughnut',
  data: {
    labels: ['Red', 'Blue', 'Yellow'],
    datasets: [{
      data: [300, 50, 100],
      backgroundColor: ['red', 'blue', 'yellow']
    }]
  },
  options: {
    tooltips: {
      callbacks: {
        label: function(tooltipItem, data) {
          var dataset = data.datasets[tooltipItem.datasetIndex];
          var currentValue = dataset.data[tooltipItem.index];
          return currentValue;
        }
      }
    }
  }
});


In this example, we are customizing the tooltip to only show the value of the data point that is being hovered over. You can customize the tooltips further by using other callback functions and options provided by Chart.js.

  1. Your doughnut chart with tooltips should now be displayed in the canvas element on your webpage.


That's it! You have successfully added tooltips to a doughnut chart in Chart.js.


What is tooltip caret size in chart.js?

In chart.js, the tooltip caret size refers to the size of the arrow that points to the data point on the chart when the tooltip is displayed. The caret size can be adjusted using the caretSize property in the tooltip configuration options. This property accepts a numerical value that represents the pixel size of the caret. By adjusting the caret size, you can customize the appearance of the tooltips on your chart.


What is tooltip item borderWidth in chart.js?

The tooltip item borderWidth in Chart.js is a property that allows you to set the width of the border around the tooltip items. By default, it is set to 1, but you can change it to any number to make the border thicker or thinner. This property is useful for customizing the appearance of tooltips in your charts.


What is tooltip intersect in chart.js?

In chart.js, the tooltip intersect option controls how tooltips are displayed when hovering over multiple elements in a chart. When set to true, the tooltip will only display when the mouse cursor intersects with an individual element on the chart. This means that if the cursor is between two elements, the tooltip will not display. When set to false, the tooltip will display for all elements that are visible within the chart area, regardless of whether the cursor intersects with them or not.
